Establish connection with ADAM network
VibroMetra always tries to establish connection with the ADAM network automatically. By double-clicking on the annunciator type
Digital output in the
selection tree, you open the settings for the ADAM network to check the connection.
As a condition for a successful connection you have to install the driver for the converter ADAM-4561 and connect the converter ADAM-4561 with the PC. If you want VibroMetra to detect an ADAM output module, you have to supply it and wire it with the converter ADAM-4561 (see
design).
As long as there is no connection, the settings are displayed as follows:
![1](drex_bullet_1.png) Close
![1. Close](drex_establish_connection_with_adam_network_control_1.png) This button closes the window.
But it can be opened again, e.g. by a double click in the selection tree.
|
|
![2](drex_bullet_2.png) Connection chart
The connection status between VibroMetra and the ADAM network is shown in a connection chart.
|
Unconnected status
|
|
Connected status
|
|
|
![3](drex_bullet_3.png) Connect VibroMetra with ADAM network
By clicking this button you connect VibroMetra to the ADAM network. You can see whether a connection has been established or not in the connection chart and in the journal.
|
|
![4](drex_bullet_4.png) Journal
The connection attempts to the ADAM network and the result are listed up here as well as entries for switching processes.
|
|
![5](drex_bullet_5.png) Close
![5. Close](drex_establish_connection_with_adam_network_control_5.png) This button closes the window.
But it can be opened again, e.g. by a double click in the selection tree.
|
|
